Area Lighting Pole features a clean, minimalist design that combines simplicity with elegance. Its versatile construction accommodates single or multi-arm brackets, allowing the installation of one or multiple luminaires to suit a wide range of area lighting applications.

Product Description
• Pole made of circular mild steel pipe.
• Pole design parameters vary depending on the type of bracket and loading factor.
• All pole sections are welded using special v groove technique by certified welders using high end MIG welding processes.
• Built-in control box with service door and vandal resistant loss proof screw.
• Die cast aluminium door is contoured to the shape of the pole with rubber gasket.
• The control gear tray is prewired with MCB, terminal connectors for loop-in / loop-out arrangement.
• The foundation bolt holes in the base plate are designed to be elongated for fine adjustments / alignment of the pole during installation.
• Base plate made of steel grade E250 & foundation bolt of grade 4.6
• CE- Conformity mark

Product Benefits
• Quick installation and low assembly costs.
• A wide range of pole heights and bracket options to meet various lighting requirements.
• Functionally versatile, strong and stable.
• Long life span.
• Innovative Design options to provide visual integration with the environment.
• Customised for your delight : Creating the entire product portfolio - Right from concept to completion, merging the best technology and practices in lighting.

Area of Application
Lighting of Buildings, Monuments, Statues, Campus Lighting, Resorts, Shipment Yards, Airports, General area lighting & Sports lightings.

Installation
Surface mounted with base plate and fitted on a pre formed foundation.

Available Finish
Coated with zinc rich primer and finished using environmentally stable polyurethane based paint / Pure polyester powder coated of desired colour.
• RAL 9004 Black
• RAL 7016 Anthracite grey
• Graphite grey
